In the current industry, low flow meters,flow meter liquid chemical flow meter industrial flow meters with high viscosity are required in many places.
For example, glue, hot melt adhesive, resin, polyurethane and other high viscosity liquids are needed in many places, and we need to control a certain flow rate to achieve a fixed amount of glue, then the glue flowmeter must be indispensable, the micro flow rate Meter, high viscosity flow meter.
We strongly recommend our own G series oval gear flowmeter, which is professionally used to measure high viscosity liquids.
The following are the style parameters for your reference:
Model: G0.15AL/G0.15SS
K factor: 0.015 ml/P
Flow range: 0.004~0.5 L/min
Gear material: SS316L
Shell material: AL/SS316L optional
Product Features
Measurement accuracy 0.5 level
Wide range 100:1
Power supply: 5-26 VDC
Working temperature: -40~100℃
Custom high temperature
Pressure: 32bar, customized high pressure
Output: Square wave pulse (Hall sensor)
Can be integrated display or with DC8S remote digital display. 4-20mA analog output,
Modbus RTU 485 communication, cumulative alarm, instantaneous alarm, etc.
Applications
G series is mainly used for dispensing, gluing, quantitative two-component polyurethane glue,
Designed to achieve high viscosity and high resolution flow detection. The measurable viscosity is up to
1 million cP medium. Low vibration and noise during work, easy to install.
Of course there are other models:
Model: G1.0AL/G1.0SS
K factor: 1ml/P
Flow range: 0.2~80 L/min
Gear material: SS316L
Shell material: AL/SS316L optional
Model: G0.1AL/G0.1SS
K factor: 0.1 ml/P
Flow range: 0.02~8 L/min
Gear material: SS316L
Shell material: AL/SS316L optional
Model: G0.04AL/G0.04SS
K factor: 0.04 ml/P
Flow range: 0.01~4 L/min
Gear material: SS316L
Shell material: AL/SS316L optional
Model: G0.4AL/G0.4SS
K factor: 0.4 ml/P
Flow range: 0.1~40 L/min
Gear material: SS316L
Shell material: AL/SS316L optional
There are many models. ..
In addition, we also have a high-frequency version of the G series, which is suitable for very high-frequency glue flow rate requirements
You can refer to the parameters:
Model: G0.2HR
Resolution: 0.003 mL/pulse
Range: 0.16~8 L/min
Model: G0.015HR
Resolution: 0.00025 mL/pulse
Range: 0.004~500 mL/min
There are many models you can refer to the picture:
sales01@cxflowmeter.com
There is also a high-pressure version of the G series:
Model: G0.1-HP-BZ
K factor: 0.1 ml/P
Flow range: 0.02~8 L/min
Gear material: SS316L (standard)/2205/PPS
Shell material: AL
Model: G0.04-HP-BZ
K factor: 0.04 ml/P
Flow range: 0.01~4L/min
Gear material: SS316L (standard)/2205/PPS
Shell material: AL
There are many models,If you want to know more, please contact winny: sales01@cxflowmeter.com
